安裝環境Installation environment | 室內Indoor? |
安裝方式Installation | 無基坑安裝, 高80MM? No foundation pit installation, high 80MM |
安裝空間installation space | 1030X860MM |
外形尺寸outline dimension | 1010X800MM |
平臺尺寸Platform size | 700X720MM |
頂層高度Top level | ≮2300MM |
停層站 Stop Station | 最大2層站Maximum 2-storey station |
最大高度maximum altitude | 最大12米Maximum 12m |
標準層高Standard level | 標準層高3.5米/每層 Standard layer 3.5 m high/per layer |
出入方向?? Access directions | 180°貫通/ 90°/或原進原出? ?180°through /90°/ or original in / out |
電源power | 1.5KW/AC220V/50HZ家用 (domestic) |
驅動方式Driving mode | 液壓驅動hydraulic pressure |
運行速度running speed | 80-120MM/秒100MM/sec |
層門控制gate control | 手動+閉門器 Manual door closers |
控制方式control method | 點動 按住運行/自動Click Hold down run / auto |
轎廂側板Car side | 5+5鋼化夾膠玻璃或鋁板噴塑 5+5 toughened with glue glass or aluminum |
轎廂門 Car door | 5MM鋼化玻璃5MM tempered glass |
控制電壓control voltage | 24V/DC |
整機顏色Machine color | 標準色:白色(可選)Standard Color: White (optional) |
最大承重Maximum load bearing | 250KG/350KG |
設備噪音noise | 小于60dB? Less than 60 dB |
工作溫度working temperature | -5C°/ +40C° |
安全裝置 safety device |
* 手動應急下降及開門裝置? Manual emergency drop and door opening device * 平臺主控面板優先? Platform master panel preferred * 緊急停止按鈕 Emergency stop button * 轎門與設備聯動控制? Car door and equipment linkage control * 轎廂底部防撞Car bottom collision * 轎廂頂部防撞 Car roof collision * 防墜落機械裝置 anti-fall mechanical device * 電控系統防過流過載保護 Electronic control system to prevent overcurrentoverload protection * 平臺超重保護?? Platform Overweight Protection * 液壓油路防爆閥?? Hydraulic oil circuit explosion-proof valve |
